The US 7002 Bentley is a primary switch mode battery charger with pulse maintenance, is designed to offer maximum life for the battery. It represents the state-of-the-art of today's technology for battery charging.
Specifications:
- MODEL: 1018
- VOLTAGE AC: 100-115VAC, 50-60Hz
- CURRENT: 2A rms
- BACK CURRENT DRAIN*: Less than 1Ah/month
*Back current drain is the current that the charger drains the battery with, if the wall socket is disconnected
- CHARGING VOLTAGE: 14.4V (Nominal 12V)
- RIPPLE **: Max 150mV rms, max 0.3A (=4%)
** Quality of the current and voltage are very important. High current ripple heats up the battery and makes the positive electrode age prematurely. High voltage ripple could harm other equipment connected to the battery. US 7002 Bentley produces a high quality current and voltage with very low ripple.
- CURRENT: 7A max
- AMBIENT TEMPERATURE: -4°F to +122°F (-20°C to +50°C), power is reduced automatically at increased ambient temperature.
- COOLING: Natural convection
- CHARGING CYCLE: US 7002 Bentley is a multi-stage fully automatic charger
- TYPE OF BATTERIES: All types of 12V lead-acid batteries (Wet, MF, AGM and most GEL)
- BATTERY CAPACITY: 14 to 150 Ah
- CEC-400 BATTERY CAPACITY: 55 to 130 Ah
- DIMENSIONS: 8 1/2 x 3 1/2 x 1 7/8 inch (L x W x H)
- ENCLOSURE: Raintight
- WEIGHT: 3.1 lbs
Fitment:
Bentayga / Bentayga EWB (2015+)
Flying Spur (2014-2019)
New Flying Spur (2020+)
Mulsanne (2011-2021)
Continental GT (2012-2017)
Continental GTC (2012-2018)
Continental GT3-R (2015)
Continental Supersports (2017-2018)
Continental Supersports Convertible (2017-2018)
New Continental GT (2019+)
New Continental GTC (2019+)
Manufacturer P/N: 3Y0915685A
